Rail-Transport Optimized Detachable Container House | Flat-Pack Modular Unit
Product Summary
Duplex-Ready Detachable Guest House (18m²): Built on a 2.3-3.0mm galvanized frame with an 8-10yr life. Features a multi-floor design with external stairs and a balcony ideal for modern backyard living cabins. Flat-pack ready: 18 sets per 40HQ. Rapid setup: 4 workers in 3h. Suppor
Basic Properties
Place of Origin:
Jiangsu, China
Brand Name:
Global Container(SuZhou)Co.,Ltd
Certification:
ISO 9001 / ISO 14001 / ISO 45001 · CE Certification · SGS Inspection · Fireproof Certificate · Wind Resistance Test · Electrical CE / IEC / UL
Model Number:
Detachable Container House
Trading Properties
Minimum Order Quantity:
4
Price:
800-1050
Payment Terms:
L/C,T/T
Supply Ability:
Up to 300 units per day
Product Description
Rail-Transport Optimized Detachable Container House | Flat-Pack Modular Unit
Product Overview
Streamline your overland supply chain with the rail-freight-optimized Detachable Flat-Pack Container House from Global House (Suzhou) Co., Ltd. Designed specifically for Central Asia's railway-dependent logistics, our modular units match the internal dimensions and clearance standards of the China-Europe Railway Express. The flat-pack design enables multiple detached units to be bundled securely into standard rail containers, significantly reducing inland cross-border freight costs while ensuring zero damage during long-distance transit.
Technical Specifications
| Parameter | Specification Details |
|---|---|
| Standard Size | 5950mm (L) x 3000mm (W) x 2800mm (H) |
| Main Frame | 2.3mm to 3.0mm Spray Painted Galvanization Steel Tube |
| Wall Partition | 50mm/75mm/100mm Rock Wool/EPS/PU Sandwich Panel with 0.3-0.5mm color steel plate |
| Roof System | 0.42mm Color Steel Plate + Insulation cotton + multi-waterproof sealing |
| Ceiling | 0.24mm Color Steel Plate |
| Floor System | 15mm/18mm MGO Board or Cement Fiber Board + PVC floor leather |
| Doors & Windows | 0.4mm Steel door; Plastic Steel Sliding Windows * 2 sets |
| Resistance | Seismic Resistance Grade 8; Wind Resistance Grade 10-11 |
| Service Life | 8 - 10 Years |
Application Scenarios
- Modern Backyard Guest Villas: Elegant detached secondary dwellings for family members, teen retreats, or home offices
- Boutique Resort & Airbnb Homestays: Multi-level holiday cabins with scenic upper balcony decks
- Premium Multi-Generational Housing: Flexible, scalable independent micro-apartments
- Private Artistic & Leisure Studios: Insulated, bright workspaces for writers, home gyms, or remote executives
Core Advantages
- Multi-Floor Vertical Architecture: Doubles domestic footprint vertically with external staircase and viewing terrace
- Exceptional Shipping Container Economics: Up to 18 complete sets per 40HQ ocean container
- Rapid Turnkey Home Setup: 4 workers can assemble one structural module in under 3 hours
- Structural Durability & Resilience: Reinforced 2.3mm-3.0mm galvanized steel framework handles Wind Levels 10-11
- Clean, Reusable Real Estate Asset: Fully unboltable and movable with zero construction waste
Installation Guide
- Site Inspection: Prepare flat layout or level concrete support piers
- Chassis Fastening: Connect primary galvanized floor perimeter framing
- Frame & Balcony Setup: Erect vertical columns and attach stairwell/balcony railings
- Enclosure Installation: Slide insulation wall panels and window systems into frame
- Residential Finishing: Install MGO flooring, PVC finish, and electrical systems
Frequently Asked Questions
Q1: Is the lower living cabin 100% leak-proof if there is rain on the upper deck?
Yes. The integrated roof infrastructure features an advanced U-shaped internal drainage network and professional-grade multi-layer sealing, ensuring the lower suite remains completely dry during severe weather.
Q2: How are the staircase and upper balcony rails packaged for international delivery?
We use specialized flat-pack breakdown technology. All components are securely bundled within the flat-pack kit to prevent transit damage and maximize shipping container space.
Q3: Can the backyard house be customized with larger windows or custom walls?
Absolutely. We provide extensive cosmetic and structural customization options including different insulation types, door/window layouts, and large glass sliding doors.
Q4: Do I need a heavy concrete foundation poured in my backyard?
No heavy civil concrete work is required. Basic leveled ground or simple pre-cast concrete pier blocks at main corner load points are sufficient.
Q5: Is stacking completely safe for a family multi-level residential duplex?
Yes. The 2.3mm-3.0mm galvanized structural steel chassis is rated for heavy vertical loads and safely supports up to 3-story configurations.
Q6: Do the insulated wall panels satisfy residential safety requirements?
Yes. We offer Grade-A fire-resistant Rock Wool or EPS sandwich wall panels that comply with strict local residential safety and fire regulations.
Q7: Can I take the house down and relocate it if I sell my property?
Yes. The detachable bolt-connected design is engineered for long-term mobility. You can unbolt the entire complex and move it without losing materials.
Q8: Are the pre-installed electrical circuits ready for immediate residential use?
We supply factory pre-wired "plug-and-play" electrical kits configured to your destination country's specific voltage, frequency, and plug criteria.
Manufacturer: Global House (Suzhou) Co., Ltd
Product Details
Highlight:
modular detachable tiny house
,modular detachable container house
,20ft detachable tiny house
Dimensions:
Standard 20ft Or 40ft Container Size
Shipment:
Ship Disassembled
Wallthickness:
50mm To 100mm
Floor Loading Capacity:
150 ㎏/㎡
Frame:
Q235B Galvanized Steel
Wallboard:
Glass Wool Sandwich Panels
Application:
Warehouse
Durability:
Weather-resistant And Corrosion-proof Coating
Wind Resistance:
100km/h
Main Materia:
Light Steel Frame & Sandwich Panel
Services:
2D Floor Plan Solution; 3D Model
Productname:
Prefabricated Container House
Cutting:
Saw Cutting
Assemblytime:
1-3 Days Per Unit
Wind Resistence:
120KM/H
