Home > Products > Detachable Container House > Heavy-Duty Detachable Site Office | Mobile Infrastructure Command Pod
Highlight:

20ft detachable tiny house

,

40ft detachable tiny house

,

20ft detachable container house

Dimensions:
Standard 20ft Or 40ft Container Size
Shipment:
Ship Disassembled
Wallthickness:
50mm To 100mm
Floor Loading Capacity:
150 ㎏/㎡
Frame:
Q235B Galvanized Steel
Wallboard:
Glass Wool Sandwich Panels
Application:
Warehouse
Durability:
Weather-resistant And Corrosion-proof Coating
Wind Resistance:
100km/h
Main Materia:
Light Steel Frame & Sandwich Panel
Services:
2D Floor Plan Solution; 3D Model
Productname:
Prefabricated Container House
Cutting:
Saw Cutting
Assemblytime:
1-3 Days Per Unit
Wind Resistence:
120KM/H
Dimensions:
Standard 20ft Or 40ft Container Size
Shipment:
Ship Disassembled
Wallthickness:
50mm To 100mm
Floor Loading Capacity:
150 ㎏/㎡
Frame:
Q235B Galvanized Steel
Wallboard:
Glass Wool Sandwich Panels
Application:
Warehouse
Durability:
Weather-resistant And Corrosion-proof Coating
Wind Resistance:
100km/h
Main Materia:
Light Steel Frame & Sandwich Panel
Services:
2D Floor Plan Solution; 3D Model
Productname:
Prefabricated Container House
Cutting:
Saw Cutting
Assemblytime:
1-3 Days Per Unit
Wind Resistence:
120KM/H
Heavy-Duty Detachable Site Office | Mobile Infrastructure Command Pod
Heavy-Duty Detachable Site Office | Mobile Infrastructure Command Pod
Product Overview

Keep your massive cross-border linear infrastructure projects moving efficiently with the mobile Detachable Site Management Office from Global House (Suzhou) Co., Ltd. Ideally engineered for long-distance highway, pipeline, and railway construction under the Belt and Road Initiative (BRI) across Central Asia, this 18m² footprint pod acts as a high-end mobile command center.

Because the unit is detachable and bolt-connected, your engineering teams can rapidly assemble it on-site and easily disassemble it into compact flat-packs to move along with the advancing construction line, drastically reducing temporary infrastructure write-offs.

Heavy-Duty Detachable Site Office - Mobile Command Center
Detailed Technical Specifications
Parameter Specification Details
Standard Size 5950mm (L) x 3000mm (W) x 2800mm (H)
Main Frame 2.3mm to 3.0mm Spray Painted Galvanization Steel Tube
Wall Partition 50mm/75mm/100mm Rock Wool/EPS/PU Sandwich Panel with 0.3-0.5mm color steel plate
Roof System 0.42mm Color Steel Plate + Insulation cotton + multi-waterproof sealing
Ceiling 0.24mm Color Steel Plate
Floor System 15mm/18mm MGO Board or Cement Fiber Board + PVC floor leather
Doors & Windows 0.4mm Steel door; Plastic Steel Sliding Windows * 2 sets
Resistance Seismic Resistance Grade 8; Wind Resistance Grade 10-11
Service Life 8 - 10 Years
Versatile Application Scenarios
  • Modern Backyard Guest Villas: An elegant, detached secondary dwelling for family members, teenage retreats, or independent home offices.
  • Boutique Resort & Airbnb Homestays: Striking multi-level holiday cabins featuring a scenic upper balcony deck to maximize customer visual appreciation.
  • Premium Multi-Generational Housing: Highly flexible, scalable independent micro-apartments that expand your living square footage without intrusive construction.
  • Private Artistic & Leisure Studios: Insulated, bright, and isolated field workspaces for writers, home gym setups, or remote executives.
Core Advantages
Multi-Floor Vertical Architecture: The specialized modular frame doubles your domestic footprint vertically. Incorporating an external staircase and viewing terrace creates an open, luxurious outdoor space while saving valuable backyard land.
Exceptional Shipping Container Economics: Engineered for optimal overseas transport; our compact breakdown packing allows a standard 40HQ ocean container to comfortably carry up to 18 complete sets, minimizing landed import costs.
Rapid Turnkey Home Setup: Bypassing lengthy local contractor timelines; a basic assembly team of 4 workers can completely bolt one structural module together in under 3 hours using everyday manual tools.
Structural Durability & Resilience: Built with a reinforced 2.3mm to 3.0mm galvanized steel framework, this residential cabin comfortably handles Wind Levels 10-11 and is certified for vertical stacking up to 3 floors high.
Clean, Reusable Real Estate Asset: Relying entirely on clean, high-strength bolted connectivity, this modular home can be fully unbolted, packed flat, and moved to your next property or city with zero construction waste or material damage.
Simplified 5-Step Installation Guide
  1. Site Inspection: Prepare a flat layout in your backyard or set up elementary, level concrete support piers at the main load-bearing corners.
  2. Chassis Fastening: Securely connect the primary galvanized floor perimeter framing to the corner castings using high-tensile structural bolts.
  3. Frame & Balcony Setup: Erect the four vertical columns, bolt the pre-sealed roof framework tightly, and attach the external stairwell and balcony railings.
  4. Enclosure Installation: Slide the high-insulation sandwich wall panels and weather-tight window systems smoothly into the precision frame channels.
  5. Residential Finishing: Lay down the premium, fire-retardant MGO flooring, roll out the durable PVC leather finish, and power up the pre-routed "plug-and-play" electrical distribution grid.
FAQ (Frequently Asked Questions)
Q1: Is the lower living cabin 100% leak-proof if there is rain on the upper deck?
Yes. The integrated roof infrastructure features an advanced, deep U-shaped internal drainage network and professional-grade multi-layer sealing, ensuring the lower bedroom/living suite remains completely dry and leak-proof during severe weather.
Q2: How are the staircase and upper balcony rails packaged for international delivery?
We use specialized flat-pack breakdown technology. All components--including the upper balcony deck posts, railings, brackets, and the steel staircase steps--are securely bundled together within the flat-pack kit to prevent transit damage and maximize shipping container space.
Q3: Can the backyard house be customized with larger windows or custom walls?
Absolutely. We provide extensive cosmetic and structural customization options. You can select different sandwich panel insulation types, customize door/window layouts, or upgrade to large glass sliding doors to maximize natural light and yard views.
Q4: Do I need a heavy concrete foundation poured in my backyard?
No heavy civil concrete work or deep foundations are required. A basic leveled ground area or simple pre-cast concrete pier blocks at the main corner load points are completely sufficient for stable operation.
Q5: Is stacking completely safe for a family multi-level residential duplex?
Yes. The 2.3mm-3.0mm galvanized structural steel chassis is rated for heavy vertical and seismic loads. It safely supports up to 3-story vertical configurations, and we supply high-tensile structural tie-plates to ensure total safety for multi-level layouts.
Q6: Do the insulated wall panels satisfy residential safety requirements?
Yes. We offer Grade-A fire-resistant Rock Wool or EPS sandwich wall panels, allowing your backyard guest home to easily comply with strict local residential safety and municipal fire regulations.
Q7: Can I take the house down and relocate it if I sell my property?
Yes. The detachable bolt-connected design is engineered specifically for long-term mobility. You can effortlessly unbolt the entire dual-level complex, pack it flat, and haul it away to your next property without losing any materials.
Q8: Are the pre-installed electrical circuits ready for immediate residential use?
We supply factory pre-wired "plug-and-play" electrical kits--inclusive of bright LED lighting networks and safe power sockets--pre-configured exactly to your destination country's specific voltage, frequency, and plug criteria.
Manufacturer: Global House (Suzhou) Co., Ltd
