Home > Products > Expandable Container House > Space Saving Expandable Modular House Compact Workspace Mobile Expandable Prefab House
Highlight:

Space Saving Expandable Modular House

,

Expandable Modular House Compact

,

Mobile Expandable Prefab House

Keyword:
Expandable Modular House
Weight:
Approximately 2,300 Kg For 20ft Unit
Assemblytime:
4-6 Hours With 2-3 Workers
Main Materia:
Light Steel Frame & Sandwich Panel
Loading:
1*40HQ Can Load 2 Units
Hue:
Blue Wood
Insulation:
Thermal And Sound Insulation Included
Furnishing:
Not Included
Steel Frame:
Galvanized Steel Bending (180g
Window:
PVC Sliding Window
Forwarding Server Ip:
119.254.30.208
Mobility:
Easily Transportable By Truck Or Ship
Side Frame:
Fully Galvanized
Warranty:
5 Years Limited Warranty
Roofing:
50mm Rockwool Sandwich Panel
Size Options:
10FT / 20FT / 30FT / 40FT
Frame Material:
Q235 Hot Galvanized Steel
Wall Panel:
75/100mm EPS / Rock Wool Panel
Installation Time:
15 - 30 Minutes
Lifespan:
15 - 20 Years
Keyword:
Expandable Modular House
Weight:
Approximately 2,300 Kg For 20ft Unit
Assemblytime:
4-6 Hours With 2-3 Workers
Main Materia:
Light Steel Frame & Sandwich Panel
Loading:
1*40HQ Can Load 2 Units
Hue:
Blue Wood
Insulation:
Thermal And Sound Insulation Included
Furnishing:
Not Included
Steel Frame:
Galvanized Steel Bending (180g
Window:
PVC Sliding Window
Forwarding Server Ip:
119.254.30.208
Mobility:
Easily Transportable By Truck Or Ship
Side Frame:
Fully Galvanized
Warranty:
5 Years Limited Warranty
Roofing:
50mm Rockwool Sandwich Panel
Size Options:
10FT / 20FT / 30FT / 40FT
Frame Material:
Q235 Hot Galvanized Steel
Wall Panel:
75/100mm EPS / Rock Wool Panel
Installation Time:
15 - 30 Minutes
Lifespan:
15 - 20 Years
Space Saving Expandable Modular House Compact Workspace Mobile Expandable Prefab House
1. Product Overview

  • Maximize the potential of every square meter in the Netherlands with the ultra-efficient Expandable Container House Series developed by Global House (Suzhou) Co., Ltd. This globally proven modular building solution offers the ultimate space-saving technology for countries with strict land constraints and high population density. Occupying merely one-quarter of its fully expanded volume during transport, it effortlessly bypasses logistical bottlenecks in dense urban centers, narrow streets, or busy port areas. Once lifted onto the site, the innovative hinged mechanism allows it to deploy in under 15 minutes, miraculously expanding into a surprisingly spacious, fully functional living or working hub. Featuring modern aesthetics, premium PVC flooring, and excellent insulation, it offers Dutch developers unmatched ROI and an incredibly versatile footprint for pop-up housing, student accommodations, or flexible workspaces.

Space Saving Expandable Modular House Compact Workspace Mobile Expandable Prefab House 0

2. Key Advantages
  • Multiplied Space & Optimized Freight:
    The unique folding mechanism allows up to 4 sets (10FT) or 2 sets (20FT) to fit inside a single 40HQ shipping container. This drastically reduces international logistics expenses per square meter.
  • Standardized Cost-Efficiency:
    Manufactured via a mature assembly line, this model provides an exceptional price advantage for bulk orders, shortening the investment payback period for developers.
  • Minimal On-Site Labor:
    No complex civil engineering is required. A team of 2–3 general laborers can complete the installation within hours using basic lifting equipment.
  • High-Turnover Mobile Asset:
    The heavy-duty bolt-together design supports repeated disassembly and relocation. Your building asset can move with your projects for multiple life cycles.
3. Specifications & Loading Capacity
Type Extended Size
L*W*H (mm)		 Folded Size
L*W*H (mm)		 Area 40HQ Loading Shipping Weight
10FT Model 2950 * 6480 * 2480 2950 * 2200 * 2480 20 m² 4 SETS ~1.8 - 2.0 Tons
20FT Model 5900 * 6480 * 2480 5900 * 2200 * 2480 38.2 m² 2 SETS 3.4 Tons
30FT Model 9000 * 6480 * 2480 9000 * 2200 * 2480 58.3 m² 1 SET ~4.5 Tons
40FT Model 11800 * 6480 * 2480 11800 * 2200 * 2480 76.4 m² 1 SET 5.4 Tons
4. Detailed Material Specifications
  • Main Steel Frame: Q235 Hot-dip galvanized steel, 2.5mm - 3.0mm thickness, with 6mm corner head liner plates for maximum structural safety.
  • Wall Panels: External wall: 75mm EPS sandwich panel standard (Upgradable to Rock Wool for premium fire resistance). Internal partition: 50mm EPS sandwich panel.
  • Roof System: External top: 0.35mm corrugated color steel sheet. Insulation: 50mm EPS sandwich panel. Internal ceiling: 200-type aesthetic ceiling board.
  • Flooring: Subfloor: 18mm fireproof magnesite board (moisture-proof & insect-resistant). Surface: 2.0mm wear-resistant PVC floor leather (Upgradable to 4.0mm SPC flooring).
  • Doors & Windows (Optional Upgrade): PVC casement windows (with anti-insect screens) + Aluminum security door.
    Available Upgrades: Broken bridge aluminum entrance doors (double glass), KFC doors, aluminum alloy sliding doors, broken bridge aluminum windows, plastic steel sliding windows, ceiling-to-floor glass windows, etc.
  • Color Customization: Wall panel colors: White, Red Wooden, Dark Gray. Frame colors: White, Black, Dark Gray. Optional: 16mm metal carved board as exterior wall decoration.
5. Target Applications

Project Camps (construction dormitories, site canteens, modular restrooms); Office Spaces (mobile office units, field command centers, temporary meeting rooms); Emergency Housing (post-disaster resettlement, refugee shelters, affordable pods); Utility Buildings (security booths, temporary clinics, mobile convenience stores).

6. How It Works (4-Step Deployment)
  1. Unloading: Lift the folded unit onto leveled, hardened ground or simple concrete piers.
  2. Unfolding Wings: Release the safety latches, lift the two roof sections in sequence, and then lower the floor sections.
  3. Fixing Walls: Push the folded side walls outward to a vertical position and install the corner connectors.
  4. Sealing: Apply prefabricated sealing strips and high-quality structural adhesive at joints to ensure a weather-tight finish.
7. Frequently Asked Questions

Q1: Are you a manufacturing factory or a trading company? Where is your factory located?
A: We are a direct manufacturing factory. Our plant is located in Zhenze Town, Wujiang County, Suzhou City, Jiangsu Province, China. We welcome global clients and third-party inspection agencies to visit us at any time.

Q2: What is the lifespan of this container house? Is it stable under extreme weather?
A: Under standard conditions, the galvanized steel frame has a lifespan of 15 to 20 years. Structurally, it is extremely safe; when properly anchored to a foundation, it can resist winds up to 200km/h and withstand up to a magnitude-9 earthquake outside.

Q3: Can the electrical and plumbing systems meet my local country's strict compliance standards?
A: Yes. We regularly export to regions with strict compliance requirements. We can pre-install electrical wiring, sockets, and plumbing systems that fully meet specific local certifications (such as CE for Europe or AU/NZS for Australia and New Zealand) to ensure fast council approval.

Q4: How long does it take to build? Do I need professional engineers?
A: No professional technicians are needed. We provide comprehensive installation videos and manuals. Generally, 2 workers can master the operation and complete a standard room setup within about 3 hours using basic lifting equipment.

Q5: What is your standard delivery time?
A: Delivery time depends on order quantities and customization. For standard sizes and configurations, delivery preparation generally takes 15 to 20 days after receiving the deposit (with standard scaling varying within 5-15 days depending on exact queue lines).

Q6: What should I provide to get a customized layout or design scheme?
A: It's very easy! If you have a sketch drawing or reference photo, you can send it to us directly. If not, simply notify us of your requirements, such as the total area, target usage, room/sanitary layout, and material preferences, and our design team will provide a detailed scheme and quotation.



Contact For Global Orders: Global House (Suzhou) Co., Ltd.
